Sinoboom 1932M Electric Scissor Lift
Sinoboom 1932M Electric Scissor Lift
1932ME
Electric Series Scissor Lift
PRODUCT HIGHLIGHTS
RELIABLE PERFORMANCE
Powerful ramp climbing capabilities
EFFICIENT AND ENVIRONMENTALLY FRIENDLY
Environmental protection, zero emissions
REDUCED MAINTENANCE COSTS
Rapid, convenient transportation with two-way forklift slot
Highly versatile parts and components you know and trust
DIMENSIONS
Max Working Height: 25’7″
Length-Stowed: 5’11”
Height-Stowed Rail Unfolded: 7′
Ground Clearance (Pothole Guard Stowed): 3″
Max Platform Height: 19′
Width-Stowed: 2’8″
Ground Clearance (Pothole Guard Deployed): 0.95″
Max Horizontal Extension: 3′
Height-Stowed Rail Folded: 6’2″
Wheelbase: 4’4″
Platform Dimensions (LxWxH): 5’5″ x 2’6″ x 3’7″
PERFORMANCE
Platform Allowable Occupants (Indoor/Outdoor): 2 Persons/1 Person
Drive Speed-Stowed: 2.5mph
Descent Time (Unloaded): 25s~30s
Tilt Rating (Front to Back/Side to Side): 3/1.5°
Platform Capacity: 507lbs
Drive Speed-Raised: 0.5mph
Gradeability: 25%
Tires-solid: 12.7×4″
Elevation Time (Unloaded): 15s~20s
Turning Radius (Inside/Outside): 0/4’11”
POWER
Batteries: 6V×4/225Ah
Charger Input: 100~240V AC
Power Source: 24V DC
Charger Output: 30A
Drive Mode: Motor, front-wheel
Hydraulic System Capacity: 2.9 gal
Weight (Indoor/Outdoors): 3,473lbs
Standards Compliance: ANSI/CSA
Floor Loading (maximum ground pressure): 178 psi/ 1230 Kpa
