JLG R1932 Electric Scissor Lift
JLG R1932 Electric Scissor Lift
$0.00
With a refreshed design that includes an electric drive, the QuikFold rail system allows operators to fold the rails in a fraction of the time compared to other machines.
Dimensions:
Platform Height (max): 19 ft (5.79 m)
Platform Height (lowered): 3 ft 3 in (0.98 m)
Platform Width: 25.4 in (0.64 m)
Platform Length: 62.7 in (1.59 m)
Platform Extension Length: 3 ft (0.91 m)
Machine Height: 6 ft 11 in (2.1 m)
Machine Height (rails folded): 5 ft 4 in (1.63 m)
Machine Length: 5 ft 9 in (1.74 m)
Machine Width: 2 ft 8 in (0.81 m)
Ground Clearance: 3 in (0.07 m)
Wheelbase: 4 ft 5 in (1.35 m)
Capacities:
Platform Capacity: 507 lb (230 kg)
Platform Capacity (extension): 265 lb (120 kg)
Number of Occupants (indoor/outdoor): 2/1
Performance:
Drive Speed (platform elevated): 0.5 mph (0.8 km/h)
Drive Speed (platform lowered): 2 mph (3.22 km/h)
Lift Time: 27 seconds
Lower Time: 28 seconds
Gradeability: 25%
Quantity:
