Sinoboom 3346E Electric Scissor Lift
Sinoboom 3346E Electric Scissor Lift
Outstanding Performance
Meets indoor & outdoor requirements
Electric drive system with integrated leak containment ensures extended battery runtime and is ideal for environmentally sensitive job sites
Compact footprint with standard folding guardrails, enabling seamless access through standard doorways
Low Maintenance
Durable structural design with side-opening doors for long machine life and easy serviceability
Onboard fault diagnostics with integrated error codes and resolution guidance—no external analyzer required
Shares many common parts with other Sinoboom scissors for simplified maintenance
Bumper protection helps prevent scratches and damage
AGM battery is included as a standard feature
Easy Operation
High platform capacity and fast lift/lower speed help complete tasks more efficiently
Optimized for transport with dual-access forklift pockets for flexible loading options
DIMENSIONS
Max Working Height: 39’10”
Length-Stowed: 8′
Height-Stowed Rail Unfolded: 8’1.6″
Ground Clearance (Pothole Guard Stowed): 4″
Max Platform Height: 32’10”
Width-Stowed: 3’10”
Height-Stowed Fixed Rail: –
Ground Clearance (Pothole Guard Deployed): 0.98″
Max Horizontal Extension: 3′
Height-Stowed Rail Folded: 6’1″
Wheelbase: 6’2″
Platform Dimensions (LxWxH): 7’7″ x 3’9″ x 3’7″
PERFORMANCE
Platform Allowable Occupants (Indoor/Outdoor): 2 Persons/1 Person
Drive Speed-Stowed: 2.5mph
Descent Time (Unloaded): 40s~45s
Tilt Rating (Front to Back/Side to Side): 3°/1.5°
Platform Capacity: 705.6lbs
Drive Speed-Raised: 0.5mph
Gradeability: 25%
Tires-solid: 15×5″
