TDE6 diaphragm pump - Capable of continuous dry operation for seepage dewatering. Handles sand, mud and sludge.

• Sand cast aluminum construction for portability and durability

• Thermoplastic rubber diaphragm

• 2-inch NPT suction and discharge size

• 1-5/8 inch diameter solids handling capability

• Modular component design permits easy maintenance and cleanout

• Electric motor model

• Delivers up to 90GPM

• Maximum temperature 180˚F

TECHNICAL SPECIFICATIONS

Suction Size: 2" NPT Coupling
Engine: N/A, Electric Motor
Max Output (hp/rpm): 4.0/1725
Dimension (L x W x H): 44 x 20 x 23
Pump Weight: 165 lbs
