Bartell forward plates are innovative, hard-hitting, and low maintenance. The BCF1570 is our most popular forward compactor and is perfect for a wide range of compaction applications. The built-in water tank allows the compactor to be used on asphalt, and also allows for better dust control on dirt/soil.

Robust throttle control mounted on handle for safe and convenient operator control

• Anti-vibration handle

• Folding handle for compact storage

• Retractable wheels flip down for built-in mobility

• Integrated lifting bale for safe loading and unloading

• Straight-edge plate design leaves no unreachable margins

• Sealed housing keeps debris from interfering with the belt

• Built-in removable water tank

• Optional urethane mat protects pavers and slabs from scratches and breakage

Engine: Honda GX160, 4.8hp (3.6kW)

Compaction Force: 3461 lbf, 15 kN,1570 kgf

Max Travel Speed: 82'/min (25m/min)

Length: 44" (1118mm)

Width: 20" (508mm)

Height: 33" (838mm)

Weight: 217 lbs (98kg)

Plate Size: 20" x 21" (500mm x525mm)
