PRODUCT HIGHLIGHTS

RELIABLE PERFORMANCE

• Powerful ramp climbing capabilities

EFFICIENT AND ENVIRONMENTALLY FRIENDLY

• Environmental protection, zero emissions

REDUCED MAINTENANCE COSTS

• Rapid, convenient transportation with two-way forklift slot

• Highly versatile parts and components you know and trust

*Payment based on 60 months at 7.5% APR - With Approved Credit

DIMENSIONS

• Max Working Height: 25’7″

• Length-Stowed: 5’11”

• Height-Stowed Rail Unfolded: 7′

• Ground Clearance (Pothole Guard Stowed): 3″

• Max Platform Height: 19′

• Width-Stowed: 2’8″

• Ground Clearance (Pothole Guard Deployed): 0.95″

• Max Horizontal Extension: 3′

• Height-Stowed Rail Folded: 6’2″

• Wheelbase: 4’4″

• Platform Dimensions (LxWxH): 5’5″ x 2’6″ x 3’7″

PERFORMANCE

• Platform Allowable Occupants (Indoor/Outdoor): 2 Persons/1 Person

• Drive Speed-Stowed: 2.5mph

• Descent Time (Unloaded): 25s~30s

• Tilt Rating (Front to Back/Side to Side): 3/1.5°

• Platform Capacity: 507lbs

• Drive Speed-Raised: 0.5mph

• Gradeability: 25%

• Tires-solid: 12.7×4″

• Elevation Time (Unloaded): 15s~20s

• Turning Radius (Inside/Outside): 0/4’11”

POWER

• Batteries: 6V×4/225Ah

• Charger Input: 100~240V AC

• Power Source: 24V DC

• Charger Output: 30A

• Drive Mode: Motor, front-wheel

• Hydraulic System Capacity: 2.9 gal

• Weight (Indoor/Outdoors): 3,473lbs

• Standards Compliance: ANSI/CSA

• Floor Loading (maximum ground pressure): 178 psi/ 1230 Kpa
